主钳适应范围(Pipe Size Range Of Master Tong): φ127-203 钻杆5“-8”

额定高档扭矩(High Gear Rated Torque):

10000N.m    7380ft.lbs

额定低档扭矩(Low Gear Rated Torque):

125000N.m   92250ft.lbs

额定高档转速(High Gear Rated Speed):

33r/min

额定低档转速(Low Gear Rated Speed):

2.2r/min

额定系统压力(Rated Operation Pressure):

18Mpa  2610psi

最大供油量(Max.Flow):

120L/min    32gpm

气动系统压力(Pneumatic  Operation  Pressure): 0.5-0.9MPa  73-131psi

外形尺寸(Dimension      L×W×H):

1750×1060×1680mm       70.9”×43.3”×57”

移运质量(含背钳)

(Weight(Including  Backup  Tong)):

2500Kg      5512lbs
